Main Features:
1.Electric walkie stacker use DC permanent magnet drive motor which provide strong power and excellent performance;
2.Maintenance-free battery;
3.Wide-view gantry design to improve work efficiency;
4.The whole forklift design is more reasonable with low center of gravity, small size and low self-weight.
Specification:
|
Brand |
|
CJLIFT |
CJLIFT |
|
Model |
|
CJWES10 |
CJWES15 |
|
Power Type |
|
Battery |
Battery |
|
Operation Type |
|
Walkie |
Walkie |
|
Service weight(incl. battery) |
kg |
560 |
560 |
|
Rated Capacity |
Q(kg) |
1000 |
1500 |
|
Load Center |
C(mm) |
500 |
500 |
|
Lifting height |
h3(mm) |
2500 |
2500 |
|
Forks size |
l/e/s(mm) |
1150/160/60 |
1150/160/60 |
|
Front Overhang |
x(mm) |
|
|
|
Turning radius |
Wa(mm) |
1440 |
1440 |
|
Max. climbing ability |
%(tanθ ) |
3/6 |
3/6 |
|
Driving speed(load/unload) |
km/h |
3.5/4 |
3.5/3.6 |
|
Lifting speed(load/unload) |
mm/s |
110/180 |
73/107 |
|
Lowering speed(load/unload) |
mm/s |
130/160 |
85/115 |
